Monitor - Oximeter PC 3000

Technical specifications
Blood Pressure NIBP Monitoring
– Measuring method: Automatic measurement by oscillating method
– Cuff inflation time: <10 seconds (typical adult cuff) – Initial cuff inflation pressure: Adult mode: <180mmHg infant mode: <120mmHg – Overpressure protection limit: Adult mode: 300mmHg Infant mode: 240 mmHg Measuring range – Systolic pressure: Adult: 40-225 mmHg Infant: 40-200 mmHg – Diastolic pressure: Adult: 20-215 mmHg Infant: 20-165 mmHg – Mean arterial pressure: Adult: 10-195 mmHg Infant: 10-150 mmHg – Measurement accuracy: Systolic ±10% Diastolic ±10% MAP ±10% – Measurement mode: Manual, Auto, STAT – Automatic measuring: 1~240min – Intervals: interval tolerance: <10s – Body temperature TEMP Monitoring – Measuring range, accuracy: 25.0°C~45.0°C, ±0.2°C Oxygen Saturation & Heart Rate SpO2 & Pulse Rate Monitoring – Transducer: dual-wavelength LED – SpO2 measuring range: 35%~100% – Low perfusion capability: 0.4%~5% – SpO2 display accuracy: 70%~100% ±3% – PR measuring range: 30bpm~250bpm – PR measuring accuracy: ±2bpm Electrocardiogram EKG ECG Monitoring – Heart rate measurement: ±0.4mVp~±5mVp – Heart rate display range: 20bpm~250bpm – Display accuracy*: ±1% or ± 2 bpm, whichever is greater – Heart rate alarm delay time: =10s – Sensitivity selection: Auto, ×1/2, ×1, ×2, ×4 tolerance: =5% – Sweeping speed: 12.5 mm/s, 25mm/s, 50mm/s tolerance: =10% – ECG noise level: =30µVP-P – ECG input loop current: =0.1µA – Input impedance: =5MO – Common-mode rejection ratio: =89dB – Time constant: Monitoring mode=0.3s – Diagnostic mode=3.2s – Frequency response: Monitoring mode: 0.5Hz~25Hz – Diagnostic mode: 0.05Hz~75Hz Respiratory RESP Monitoring – Monitoring range, accuracy: 0rpm~120rpm, ±5% or 2rpm, whichever is greater – RESP alarm range: 0bpm~100bpm – Alarm tolerance: ±10% Other technical specifications – Power supply: 100~250Vac, 50/60Hz – Power consumption: <80 VA – Display mode: 7 inches TFT color LCD – Alarming mode: Audible-visual alarm – Networking port: LCD serial/Net port They contain: – 1 EKG cable – 1 SpO2 cable – 1 power cord – 1 Li-ion battery – 1 pressure cuff – Body temperature sensor – charging cable – 10 electrodes – User manual in English
