Ultrasound B&W Chison 12“ LED ECO 2 + doppler without head

Brochure: Chison-ECO2-Brochure-EN

Image processing:
– composite imaging
– trapezoidal
– I-image intelligent image optimization
– THI (Tissue Aesthetic Imaging)
– SRA (Sensitive Noise Reduction Algorithm)
– Color
– fully digital beamform
– AIO (Automatic Image Optimization)
– full screen display

User interface:

• • fold-down control panel and alphanumeric keypad

• • backlit keyboard for good visibility in a dark room

• • configurable backlight

• • illuminated lights indicate activated keys
• • 8-position TGC (time gain compensation) for easy adjustment
  • • shortcut button for quick adjustment (user-defined)
  • • Good and clear keyboard layout, so that the doctor can easily remember
  • • Preset function configurable by each user

  Improved workflow with a 6-in-1 button for:

  1. Select desired application from automatic preset
  2. Optimize image automatically (AIO)
  3. Run report
  4. Save still image and CINE loop
  5. Measurement
  6. Printing to PC printer (laser or inkjet) or video printer

  EASYVIEW™ archiving system:
  – image archive on hard disk and USB portable storage media
  – 3 USB ports
  – image format: BMP, JPG, DCM, CIN, avi
  – review repeat: automatic, manual (auto-resolution segment can be set) for 2D, M images
  – memory capacity (256 frames / 10 seconds)

  Technical specifications
  – Dimensions: 33.5 x 15.5 x h 35 cm (13.2″ x 6.1″ x h 13.8″)
  – Weight: 6 kg
  – Display: 12″ LED, high resolution 1024 x 768
  – Power: AC 100-240 V – 50/60 Hz
  – Software (user switchable language): GB, IT, FR, ES, DE, CZ, TR, CN, ES
  – User Manual: English

  Main components:

  • • 12″ High Resolution Black and White LED Display
  • • 8G Memory Card
  • • Hot Key
  • Printer Connection computer

• • 3 USB Ports

• • 1 Ethernet Port

• • 1 Video Out Port, 1 VGA Out Port

• • 1 Footswitch Port

• Show Full screen

• • Charger

• • Standard software package

• • Easy View image archiving system

• • THI
